Econami Sound Decoders
Available in three formats to suit a variety of steam, diesel and electric locomotives, Econami provides high-quality 16-bit sound, Hyperlight lighting effects, and Hyperdrive2 advanced motor control for enhanced realism. New features include Flex-Map technology, an easy-to-use method for assigning any function to any function key.
Steam and diesel versions include a selection of exhaust chuffs or prime movers, along with 16 whistles or airhorns to suit the most popular models. In addition, each decoder features multiple options for airpumps or compressors, bells, and couplers for even more customization. And finally, for the first time ever, each format is available in an electric version that includes a trolley bell, air whistles, generator, pantograph, pneumatic doors, and more!

ECO-100
Soundtraxx smallest sound decoder, this micro 1-amp, universal-style format is ideal for small models with minimal space. It includes an optional capacitor or can be wired to a CurrentKeeper (P.N. 810140) to maintain performance over dirty track and switches.
  • Dimensions: 27 x 10.5 x 5mm
  • Max. Motor Stall Current: 1A
  • Function Outputs: 4
  • Max. Function Current: 100mA (each output)
  • Audio Amplifier: 1W, 8-Ohm Load
  • DCC Track Voltage: 10V – 22V
ECO-21P
This 1-amp digital sound decoder simply plugs into models equipped with an NMRA-supported 21-pin socket, such as recent Bowser and InterMountain Railway models.
  • Dimensions: 30.5 x 15.5 x 6.5mm
  • Max. Motor Stall Current: 1A
  • Function Outputs: 6
  • Max. Function Current: 100mA (each output)
  • Audio Amplifier: 2W, 8-Ohm Load
  • DCC Track Voltage: 10V – 22V
ECO-400
This 4-amp, universal-style digital sound decoder is suitable for a variety of scales, and includes a connector to easily add a CurrentKeeper (P.N. 810140) to maintain performance over dirty track and switches.
  • Dimensions: 69 x 30.5 x 14mm
  • Max. Motor Stall Current: 4A
  • Function Outputs: 6
  • Max. Function Current: 100mA (each output)
  • Audio Amplifier: 3W, 8-Ohm Load
  • DCC Track Voltage: 10V – 26V

Our Price $99.98 1 AMP ECO-100, ECO-21P
$194.98 4 AMP ECO-400

ETA August 2015
Part Number Price Steam Diesel Electric
ECO-100 1 Amp $99.98
ECO-21P 1 Amp $99.98
ECO-400 4 Amp $194.98
